Angle Type Globe Valve
Standards compliance
Design & Manufactured to BS 1873, ASME B16.34 or DIN3202 ,ASME B16.34
Face to Face dimensions to ASME B16.10
Flanged Ends to ASME B16.5
Butt-weld Ends to ASME B16.25
Inspect & Tested to API 598
Size Ranges from 1 1/2” thru 24”
Structured in Bolted Cover, Outside Screw and York
Pressure Ratings from Class 150 to Class 1500, PN16 to PN260
Ends Connections in Flanged R.F or RTJ, Butt-welded and Grooved
Body Materials available in Cast Carbon Steel, Cast Low Carbon Steel, Cast Alloy Steel, Cast Stainless Steel, Cast Duplex & Super Duplex Steel, Special Materials in Cast Monel, Alu. Bronze etc.
Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials
Actuations can be equipped with Handwheel, Gear Devices, Electric / Pneumatic or Hydraulic Actuators
Optional Globe Check, Bypass system, Live Loading Packing& O-ring Seal
GAIRUI Angle Type Globe Valve is a new type of globe valve. Because the valve is double seal design, its sealing performance is more reliable than that of common cut-off valve. The metal barrier formed by the bellows can prevent leakage. The packing can also provide a seal after the failure of the bellows. It can be used more safely, energy saving, environmental protection and zero leakage. More than DN150 products, adding triangle positioning device, effectively prevent the valve in the use of trembling, noise, and cause damage to the inner parts, the service life effectively increased by more than 150%. The valve body is made of German coated sand casting technology, which greatly improves the surface smoothness and mechanical properties of the valve body, reduces the appearance of holes, sand holes and cracks, and strengthens the tensile strength of the castings. Products are used in steam system, heat transfer oil system, cold and hot water system, etc.
