Y Type Globe Valve
Technical Specification
Normal Size Range: 1/2"- 2"
Normal Pressure Rating: PN10~PN420, CLASS150~2500
Material: A105,LF2,F11,F22,F304,F304L,F316,F316L
Temperature Range: -29~550 Degree C
Standards compliance
Design and Manufacture: API602
Face to face(end to end): ASME B16.10
Flanged connection: ASME B16.5
Butt welded end: ASME B16.25
Socket-Welding Ends: ASME B16.11
Screwed Ends: ASME B1.20.1
Test and inspection: API598
GAIRUI Y Type Globe Valves is suitable for cutting or connecting medium on the pipes of various working conditions such as the nominal pressure of PN1.6 to 6.4Mpa, the working temperature of -29 to 550Degree C, such as oil, chemical, pharmaceutical, chemical fertilizer, electric power industry and so on. Suitable medium is water, oil, steam, acid medium, etc. The operation methods are: manual and pneumatic.
